DIY Rustic Farmhouse Bench Tutorial

Hello from Ohio! My name is Larissa, and I spend most of my days over at my blog, Prodigal Pieces, dabbling in DIY projects. I am delighted to be here today with you, Remodelaholics, because I want to share my tutorial for a simple rustic farmhouse style bench.

Build this small rustic farmhouse bench for under $20! Tutorial from Prodigal Pieces on Remodelaholic.com

I live in the heart of farm country where reclaimed barn wood abounds, and love to make use of those resources around me.  However, for most of you, that resource isn’t always available and you crave the farmhouse look. So, today I’m going to show you how to take your typical box store pine and turn it into a functional, rustic, farmhouse style bench that can be used in your entry, mudroom, bedroom…the possibilities are endless!

How to Build a Rustic Farmhouse Bench

For this project, we’re using a 2″ x 12″ x 8′ pine board that you can locate at most any DIY store, and typically only costs around $10. To get started, here are the tools/supplies you’ll need:

  • 1 – 2″ x 12″ x 8′ pine board (you can use any species of wood)
  • protective eye wear/ear plugs
  • table saw
  • jig saw
  • router / router bit (3/8″ & 5/16″- or bigger)
  • square
  • drill / drill bits (7/64″ & 3/8″)
  • sander – I prefer orbital for ease of use
  • 150 grit sandpaper
  • tape measure
  • cardboard – or something similar to make a stencil
  • oval picture frame – or similar shaped item
  • utility knife/scissors
  • 1 1/2″ screws
  • wood glue
  • 3/8″ wood plugs – optional
  • stain and/or paint
  • wax or poly topcoat – optional

When you’re purchasing your wood, don’t just grab the first board you see. Take a second and pull it out. Look for splits, warping, too many knots, etc. Be selective so that you get what you pay for.

Let’s start building!

The finished dimensions for this bench are 28 3/8″ L x 9 1/8″ D x 19″ H. In order to achieve that you’ll need this cut list:

  • 2 – 19″ boards for the ends
  • 2 – 27″ boards for the seat/shelf

The design of this bench requires that the seat/shelf be a tongue & groove design to add extra durability, so those boards are actually cut longer initially because they will be inset to the side supports.

Once you’ve cut your boards, you’ll want to take one of the 19″ boards and trace the outline on a piece of cardboard (or paperboard, or piece of paper).

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

To create those cut-out sides I used a thrifted oval picture frame (11″ x 9 1/4″), but really you could use any shape or object you like, or even omit the cut-out all together, but note it will change the layout of the assembly. This feature is more for asthetics than anything.  Just lay the oval shape 3″ down from the top edge and about 1 7/8″ in from the edge.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Next, you’ll want to make the triangular cut-out from the bottom.  Find the center of the bottom of the stencil at 4 5/8″ and mark. From the center mark, measure 4.5″ up and mark.

Measure 1.5″in from the bottom corners and mark.

Using your square, connect the corner marks to the centered mark.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Your stencil should look like this after cutting out those traced shapes.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Lay your stencil on your board and trace on both sides.  I trace on both sides because when using a jig saw, sometimes it can cut a bit wonky when working on a thick board and having the opposing tracing can help line things up if you need to flip it and tweak the cuts.

Next, grab your jig saw and cut out the traced shapes.  (Be sure to use protective eyewear!) If you have a band saw that would be slightly easier, but a standard jig saw will do the job.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

(Yes, I’m outside in 5 degree weather working, but hey, it’s Ohio!)

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Now you’ve got your rough cut end pieces and it’s time to sand.  Because pine is a soft wood and I’m going for a rustic appeal, I only use a 150 grit sandpaper, but typically with a hardwood I would start out at a 120 grit and work up to a 220 grit or higher finish.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Time to head over to the table saw to create a tongue on the seat and shelf. Set your blade to 1/4″ height and your rail to 5/8″. *Explanation: We are wanting a tongue depth of 3/4″, so to achieve that your rail is set to 5/8″ and then you add the width of the blade, which is 1/8″ – those added together give you the correct 3/4″ depth.

We used a standard blade, but a dado blade would be preferred if you have it – we wanted to show you that you don’t need tons of specific tools.  Use several passes to “chew” away the wood.  You will need to do this to all four sides.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

In order for the tongue we just created to work, we need to create a groove for it to go into. On our side pieces, we’re going to measure  2 7/8″ down from the top on both sides and mark across, stopping 1/4″ from the edge. Next, draw another line 1″ above the first line to create a box.

For the bottom shelf, measure 6″ up from the bottom on both sides and mark across, stopping 1/4″ from the edge. Next, draw another line 1″ below the first line to create another box. Here’s what the finished dimensions should be:

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

With your router, you will want to make several passes to hollow out a notch 3/4″ deep – which is where the tongue is going to go into. When finished, lightly hand sand the edges to get a clean edge.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

You’ve cut, sanded, and routed, and now it’s time to assemble.

To make things easier, you’ll need to drill pilot holes through the groove using a 7/64″ drill bit (or similar), 2″ in from each side and centered top to bottom. (No, that’s not my beefy arm, but my fantastic husband who helped me in this project – wink, wink.)

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Next, flip the side over and using a 3/8″ drill bit, you’re going to create a counter-sunk hole so that your screw head will rest below the surface and create room for the wood plug to rest.  Be light on drilling so you don’t go too deep. As a precaution, you can even put tape on your bit about 1/4″ from the end to be a depth gauge.

predrill-split-screen

In woodworking, it’s always good to do a dry fit to make sure all pieces fit together and are snug. Once you’re sure it all fits nicely together, apply wood glue to the tongue as well as inside the notch.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Lay the side piece on the floor and then insert the seat & shelf into the notches. Then add the other end piece to the top, making sure to add glue to the tongues and notches.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

While the bench is still on its side, secure it together with the screws.

Add the wood caps to finish it off and then the build is done. It’s best to let it dry overnight, but a couple of hours should suffice since the screws are holding it in place.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Onto the finish work!  Now you can take it from here to whatever style you like, and as an example I’ve taken the same bench and given it two different finishes.

A rustic style with stained finish using my favorite Varathane Early American stain.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Or maybe your taste is more of a shabby chic, cottage style, and you prefer a distressed time-worn look with a whitewashed effect. For this variation, I stained as before, but this time I used my cheapo flat ceiling paint to add a washed layer.

DIY Farmhouse Bench Tutorial by Prodigal Pieces for Remodelaholic

Both will look fantastic in your cottage, shabby chic, or farmhouse style decor. You can even paint it solid with a gloss finish for a modern twist. Have fun and make it your own.

Got questions? Just let me know and I’ll be more than happy to help. If you like this project, I’m sure you’ll love my DIY barn wood shutters from weathered pallets.

DIY Barn Wood Shutter from Pallets by Prodigal Pieces for Remodelaholic

Making your home your own shouldn’t make you broke! All it takes is desire and a DIY attitude. Until next time!

————————————
